HPE™ Cooling Unit

The HPE™ Cooling Unit is a high-performance, space-saving water chiller designed to provide precise and reliable temperature control for electrophoresis systems. It is specifically engineered to support up to four HPE™ BlueHorizon™ units simultaneously, ensuring consistent cooling without performance loss.

Purpose and Application

• Provides stable cooling for electrophoresis separations
• Designed for use with HPE™ Tower and HPE™ BlueHorizon™ systems
• Protects sensitive cooling plates from thermal damage
• Suitable for demanding laboratory workflows requiring precise temperature control

Advanced Cooling Technology

The unit features a unique suction and pressure pump system that minimizes pressure in peripheral lines. This design helps ensure gentle and safe operation, particularly for sensitive HPE™ cooling plates.

An optional Pt sensor can be added for precise temperature measurement and readout, improving monitoring and control accuracy.

Key Specifications

• Temperature stability: ±1°C
• Cooling capacity at 0°C: 0.2 kW
• Flow rate (pressure pump): 14 L/min at 0.25 bar
• Flow rate (suction pump): 10.4 L/min at 0.17 bar
• Filling volume: 1.7 L
• Dimensions: 225 × 360 × 380 mm
• Weight: 23 kg

Key Benefits

• Supports up to four HPE™ BlueHorizon™ units simultaneously
• Stable and precise temperature control for electrophoresis applications
• Low-pressure system protects sensitive equipment components
• Compact design with high cooling performance
• Optional temperature monitoring with Pt sensor
